产品应用

        全自动液压拉紧装置主要用于维持输送带恒定张力，解决因负载波动、温度变化或皮带延伸导致的张力失衡问题，防止打滑、跑偏、断带等故障。其功能包括：

1. 动态响应：实时监测输送带张力变化，通过液压系统自动补偿松弛或过紧状态，确保启动、运行、制动各阶段张力稳定；
2. 缓冲保护：吸收输送机启停时的冲击载荷，减少对电机、减速机等核心部件的瞬时冲击；
3. 延长寿命：通过优化张力分布，降低皮带与滚筒的异常磨损，延长输送带寿命30%-50%；
4. 节能降耗：避免因张力过大造成的额外摩擦损耗，系统能耗降低 10%-15%。

        全自动液压拉紧装置适用于长距离（＞ 500m）、大倾角（＞ 15°）或重载（＞ 2000t/h）等复杂工况，是保障输送系统安全高效运行的核心组件。 全自动液压拉紧装置广泛应用于化工、垃圾处理、电力、煤矿、矿山、建材、有色冶金、原料堆场、港口码头等领域。

Product Application

        The fully automatic hydraulic tensioning device is mainly used to maintain a constant tension of the conveyor belt, solve the problem of tension imbalance caused by load fluctuations, temperature changes, or belt extension, and prevent faults such as slipping, deviation, and belt breakage.

         Its core functions include:Dynamic response: Real time monitoring of changes in conveyor belt tension, automatic compensation of relaxed or overly tight states through hydraulic systems, ensuring stable tension during start-up, operation, and braking stages;

        Buffer protection: Absorbs the impact load during the start and stop of the conveyor, reducing the instantaneous impact on core components such as motors and reducers;

        Extend lifespan: By optimizing tension distribution and reducing abnormal wear of the belt and drum, the lifespan of the conveyor belt can be extended by 30% -50%;

        Energy saving and consumption reduction: Avoid additional friction losses caused by excessive tension, and reduce system energy consumption by 10% -15%.

        Especially suitable for complex working conditions such as long distances (>500m), large inclination angles (>15 °), or heavy loads (>2000t/h), it is the core component that ensures the safe and efficient operation of the conveying system.

        Widely used in fields such as chemical engineering, waste treatment, electricity, coal mining, mining, building materials, non-ferrous metallurgy, raw material storage yards, ports and terminals.

产品特点

1. 全自动智能控制

        闭环控制系统：集成张力传感器、PLC 与电液比例阀，实时采集张力信号（精度 ±2%），动态调节液压缸行程，响应时间＜ 0.5 秒；
        多模式运行：支持恒张力、时间梯度、速度跟随等模式，适配不同工艺需求；
        故障自诊断：内置压力、温度、液位监测模块，异常时自动报警或切换备用油路。

2. 高效液压驱动

• 高压模块化泵站：采用变量柱塞泵（压力范围 1-25MPa），流量按需分配，节能 30%-40%；
• 蓄能器缓冲：氮气蓄能器吸收启停冲击，降低峰值压力波动 50% 以上；
• 双缸同步技术：通过比例阀或机械联动确保双液压缸同步误差＜ 1mm，防止偏载。

3. 紧凑耐用结构

• 空间优化：拉紧行程可达 0.5-6m，占用空间较机械张紧装置减少 40%；
• 耐磨组件：液压缸镀硬铬处理（厚度 0.05-0.1mm），活塞杆抗腐蚀寿命超 10 万次；
• 环境适应性：防护等级 IP65，液压油抗污染等级 NAS 7 级，适应粉尘、潮湿、振动环境。

4. 维护便捷性

• 快换接口：液压管路采用 SAE 法兰或卡套接头，10 分钟内可完成泵站更换；
• 可视化监控：HMI 触摸屏实时显示压力、行程、故障代码，支持远程物联网接入；
• 长周期免维护：密封件寿命＞ 5 年，换油周期延长至 8000 小时（传统系统为 2000 小时）。

Product Features

1. Fully automatic intelligent control

        Closed loop control system: integrated tension sensor, PLC and electro-hydraulic proportional valve, real-time collection of tension signals (accuracy ± 2%), dynamic adjustment of hydraulic cylinder stroke, response time<0.5 seconds;
        Multi mode operation: supports constant tension, time gradient, speed following and other modes to adapt to different process requirements;
        Fault self diagnosis: Built in pressure, temperature, and liquid level monitoring modules, automatically alarm or switch to backup oil circuit when abnormal.

2. Efficient hydraulic drive

        High pressure modular pump station: using variable displacement piston pump (pressure range 1-25MPa), flow is distributed according to demand, saving energy by 30% -40%;
        Buffer of accumulator: The nitrogen accumulator absorbs start stop shocks and reduces peak pressure fluctuations by more than 50%;
        Dual cylinder synchronization technology: By using proportional valves or mechanical linkage, the synchronization error of the dual hydraulic cylinders is ensured to be less than 1mm, preventing unbalanced load.

3. Compact and durable structure

        Space optimization: The tightening stroke can reach 0.5-6m, occupying 40% less space than mechanical tensioning devices;
Wear resistant components: Hydraulic cylinder coated with hard chrome (thickness 0.05-0.1mm), piston rod with a corrosion resistance life of over 100000 times;
        Environmental adaptability: Protection level IP65, anti pollution level NAS 7 for hydraulic oil, suitable for dust, moisture, and vibration environments.

4. Maintain convenience

        Quick change interface: The hydraulic pipeline adopts SAE flange or sleeve joint, and the pump station replacement can be completed within 10 minutes;
        Visual monitoring: HMI touch screen displays real-time pressure, travel, and fault codes, supporting remote IoT access;
        Long cycle maintenance free: The lifespan of the seal is over 5 years, and the oil change cycle is extended to 8000 hours (compared to 2000 hours for traditional systems).

型号系列	安装方式	主要技术参数
		张紧行程(m)	额定张紧力(KN)	最大张紧力(KN)
KHDLA	0 0	2~6	50~200	75~300
	-01	4~10	50~200	75~300
	-02	9~12	80~150	120~300
KHDLB	-01	0.5~1.5	30~80	45~120
	-02	0.5~6	50~200	45~300
KHDLC	-01	6~36	50~300	75~450
	-02	6~18	300~500	450~750
说明	1、拉紧装置技术参数(张紧力、张紧行程)超出本表范围，可特殊设计；         2、B系列可带自动纠偏功能；         3、可以根据用户要求，对自动控制部分特殊设计，如比例控制、中文人机界面、张力值数字化传输、5秒内快速响应功能；         4、可以根据用户环境要求，防水、防盐雾，防护等级为IP55或IP65。         5、选型：如ZYLA-01-4/150,表示A系列，01安装方式，张紧行程序米，额定张紧力150KN。

Model	Installation method	Main technical parameters
		Tension stroke (m)	Rated tension force (KN)	Maximum tension force (KN)
KHDLA	0 0	2~6	50~200	75~300
	-01	4~10	50~200	75~300
	-02	9~12	80~150	120~300
KHDLB	-01	0.5~1.5	30~80	45~120
	-02	0.5~6	50~200	45~300
KHDLC	-01	6~36	50~300	75~450
	-02	6~18	300~500	450~750
Note	1. The technical parameters of the tensioning device (tensioning force, tensioning stroke) exceed the range of this table and can be specially designed;         2. B series can be equipped with automatic correction function;         3. According to user requirements, special designs can be made for the automatic control part, such as proportional control, Chinese human-machine interface, digital transmission of tension values, and fast response function within 5 seconds;         4. According to the user's environmental requirements, it can be waterproof, salt spray resistant, and have a protection level of IP55 or IP65.         5. Selection: such as ZYLA-01-4/150, indicating A series, 01 installation method, tensioning program meter, rated tensioning force of 150KN.
